STT

Description

Parts number

1

Clamp

9C1-41A-002

2

Screw

9C1-41A-002a

3

Cap

9C1-41A-003

4

Bracket

9C1-41A-004

5

Screw

9C1-41A-004a

6

Cover

9C1-41A-005

7

Screw

9C1-41A-005a

8

Guide

9C1-41A-006

9

Bolt

9C1-41A-006a

10

Holder

9C1-41A-008

11

Bolt

9C1-41A-009

12

Washer

9C1-41A-012

13

Bracket

9C1-41A-026

14

Bolt

9C1-41A-026a

15

Roller

9C1-41A-027

16

Lever assy

9C1-41A-028

17

Nut

9C1-41A-028a

18

Bolt

9C1-41A-028b

19

Ring

9C1-41A-028C

20

Pin

9C1-41A-030

21

Bolt

 9C1-41A-030a

22

Boss

9C1-41A-031

23

9C1-41A-033

24

Spring

9C1-41A-034

25

Magnet

9C1-41A-035

26

Washer

9C1-41A-037

27

Collar

9C1-41A-040

28

Nozzle assy

9C1-41a-051

29

Bolt

9C1-41A – 051a

30

Joint

9C1-41A –052

31

Bolt

9C1-41A-052a

32

Packing

9C1-41A-061

33

Damper

9C1-41A-070

34

Case assy

9C1-41A-901

35

Link assy

9C1-41A-906

36

Solenoid

9C1-E01-103

37

Scew

9C1-E01-103a

38

Solenoid assy

9C1-E01-405

39

Screw

9C1-E01-405a

40

Guide

9C1-41A-038

41

Bolt

9C1-41A-038a

42

Lever

9C1-41A-041

43

Nut

9C1-41A-041a

44

Bolt

9C1-41A-041b

45

Rob

9C1-41A-042

46

Ring

9C1-41A-042a

47

Plate

9C1-41A-043

48

Boss

9C1-41A-044

49

Washer

9C1-41A-044a

50

Shoe

9C1-41A-045

51

Bolt

9C1-41A-044b

52

Washer

9C1-41A-046

53

Shaft

9C1-41A-049

54

Screw

9C1-41A-09a

55

Bolt

9C1-41A-050a

56

Lever assy

9C1-41A-903

57

Lever assy

9C1-41A-904

58

Holder assy

9C1-41A-905

59

Base

9C1-41A-024

60

Bolt

9C1-41A-024a

61

Guide

9C1-41A-082

62

Guide

9C1-41A-083

63

Bolt

9C1-41A-083a

64

Stud

9C1-510B-011

65

Pin

9C1-510B-012

66

Packing

9C1-510B-014

67

Screw

9C1-510B-015

68

Bearing

9C1-510B-016

69

Ring

9C1-510B-016a

70

Pulley ( timing)

9C1-510B-018

71

Shaft

9C1-510B-020

72

Ring

9C1-510B-020a

73

Frame

9C1-510B-021

74

Bolt

9C1-510B-021a

75

Guide

9C1-510B-022

76

Bracket

9C1-510B-023

77

Cover

9C1-510B-024

78

Ring

9C1-510B-045

79

Bush

9C1-510B-049

80

Cap

9C1-510B-051

81

Filter

9C1-510B-055

82

Case

9C1-510B-056

83

Bolt

9C1-510B-056a

84

Motor

9C1-E01-012

85

Bolt

9C1-E01-012a

86

Washer

9C1-E01-012b

87

Sensor

9C1-E01-255

88

Cable assy

9C1-E01-356

89

Plate assy

9C1-510B-025

90

Bolt

9C1-510B-025a

91

Bearing

9C1-510B-027

92

Ring

9C1-510B-029

93

Cap

9C1-510B-040

94

Ring

9C1-510B-044

95

Seal

9C1-510B-046

96

Collar

9C1-510B-047

97

Cover

9C1-510B-048

98

Bolt

9C1-510B-048a

99

Cover ( assy )

9C1-510B-050

100

ARM assy

9C1-510B-904

101

Cylinder

9C1-506-010

102

Piston

9C1-506-011

103

Seal

9C1-506-013

104

Cap

9C1-506-014

105

Spring

9C1-506-016

106

Packing

9C1-506-021

107

Ring

9C1-506-022

108

Bracket

9C1-506-002

109

Cover

9C1-510B-013

110

Base assy

9C1-510B-902

111

Bearing center

9C1-150-001

112

Holder

9C1-150-003

113

Holder

9C1-150-005

114

Wheel

9C1-610-010
